EK waterproof strobe strip
Our factory specializes in designing and manufacturing EK waterproof strobe strip. We look forward to cooperating with you.
Send Inquiry
Product Description
You can rest assured to buy EK waterproof strobe strip from our factory. You can consult us now, we will reply to you in time!
Optical parameters of EK waterproof strobe strip
Light source: 240 R/G/B/W, 1W 3030 SMD domestic lamp beads
Color temperature: 2800K-8000K
Light output of the whole machine: R:5376 Lm; G: 16585 Im; B:2977 Im; W:20968 Im; ALL: 17400 Im
Illuminance: ALL:408 Lux; R: 140 Lux; G: 384 Lux; B: 61 Lux; W: 509 Lux@5 meters Raz90
Color rendering index: R9≥90
Dominant wavelength: R: 622nm; G: 525nm; B:457nm
Light source life: 20,000 hours
Beam angle: 120°
Dynamic effect
Strobe: 0~30Hz
Dimming: Four dimming curves, 0~100% dimming
Input voltage and frequency: 100~240VAC, 50~60Hz
Power: 300W at full brightness, 600W at strobe
Power connection: waterproof POWERCORN input/output; maximum connection quantity 9 units @230V
Signal connection: waterproof 3-core DMX signal line input/output, maximum connection quantity 32 units; waterproof network signal input and output
Power factor: 0.95@230V
Working environment: -10°~45°
Switching power supply: 100~240VAC, 50~60Hz, 36V 350W
Product size: 1000*83*119m
Net weight: 7.6Kg (excluding lamp hook and lamp hook quick lock)
Protection level: IP65
Cooling system: Waterproof low-noise fan forced cooling
Casing: Die-cast magnesium + aluminum alloy; black
Installation method: Side hanging, hanging installation
Control method: Artnet/DMX512/RDM
DMX channel: 1/3/4/5/6/8/11/15/60/62/67/120 CH/ADVANCED1/ADVANCED2
Display: OLED
Refresh rate: 600Hz/1200 Hz/2000 Hz/4000 Hz/6000 Hz/25KHz
Pixel matrix: 15*1
Inventory: 200 units
Optical parameters of EK waterproof strobe strip
Light source: 240 R/G/B/W, 1W 3030 SMD domestic lamp beads
Color temperature: 2800K-8000K
Light output of the whole machine: R:5376 Lm; G: 16585 Im; B:2977 Im; W:20968 Im; ALL: 17400 Im
Illuminance: ALL:408 Lux; R: 140 Lux; G: 384 Lux; B: 61 Lux; W: 509 Lux@5 meters Raz90
Color rendering index: R9≥90
Dominant wavelength: R: 622nm; G: 525nm; B:457nm
Light source life: 20,000 hours
Beam angle: 120°
Dynamic effect
Strobe: 0~30Hz
Dimming: Four dimming curves, 0~100% dimming
Electronic parameters
Input voltage and frequency: 100~240VAC, 50~60Hz
Power: 300W at full brightness, 600W at strobe
Power connection: waterproof POWERCORN input/output; maximum connection quantity 9 units @230V
Signal connection: waterproof 3-core DMX signal line input/output, maximum connection quantity 32 units; waterproof network signal input and output
Power factor: 0.95@230V
Working environment: -10°~45°
Switching power supply: 100~240VAC, 50~60Hz, 36V 350W
Structural parameters
Product size: 1000*83*119m
Net weight: 7.6Kg (excluding lamp hook and lamp hook quick lock)
Protection level: IP65
Cooling system: Waterproof low-noise fan forced cooling
Casing: Die-cast magnesium + aluminum alloy; black
Installation method: Side hanging, hanging installation
Control method: Artnet/DMX512/RDM
DMX channel: 1/3/4/5/6/8/11/15/60/62/67/120 CH/ADVANCED1/ADVANCED2
Display: OLED
Refresh rate: 600Hz/1200 Hz/2000 Hz/4000 Hz/6000 Hz/25KHz
Pixel matrix: 15*1
Inventory: 200 units
